SVC-N New Model of Ultra low-votlage series of Votlage Stabilizer,is an innovated designed product which based on our
ordinary model of SVC series of Voltage Stabilizer. It has the function of wide input voltage range,and perfect under-
voltage,over-voltage as well as output delaying protections.Creatively designed an unique protective function of cutting the
input voltage when overvoltage were occurring.Re-designed its' stabilizing components and control circuit in case of fire
hazard and other possible dangerious situations that caused by over-voltage and range-exceeding on the input side.This
series of model has the advantage of good internal-craftwork,perfect designed appearance ,excellent and stabilized

performance,and it is one of the newest products that Hossoni has launched at present.

Spec(KVA)		Product size D*W*H(cm)	Package size D*W*H(cm)	Weight (kg)	Qty/Ctn
Single phase two wire	SVC-N0.5KVA	18x19.5x14	44x25x35	5	4
	SVC-N1KVA	22x21x16	50x28x40	7	4
	SVC-N1.5KVA	21x22.5x16.5	50x28.40	8	4
	SVC-N2KVA	28x24x21	37x32x34	14	1
	SVC-N3KVA	31x24x26	40x31x34	16	1
	SVC-N5KVA	32x26x29	52x30x35	27	1
	SVC-N8KVA	37.5x28x31	52x30x35	40	1
	SVC-N10KVA	37.5x28x31	52x30x35	41	1
	SVC-N15KVA	45x35x70	48x45x90	75	1
	SVC-N20KVA	45x35x70	68x48x90	110	1
	SVC-N30KVA	55x45x105	64x53x112	165	1
	SVC-N45KVA	55x45x105	90x65x140	200	1
Three phase four-wire	SVC-N-3/1.5KVA	37x36.5x17.5	52x48x28	18	1
	SVC-N-3/3KVA	39x38.5x17.5	54x50x31	23	1
	SVC-N-3/6KVA	37.5x28.5x68	48x40x78	27	1
	SVC-N-3/9KVA	35.5x33x79	48x45x90	48	1
	SVC-N-3/15KVA	38.5x43.5x79	55x51x90	85	1
	SVC-N-3/20KVA	43.5x51.5x97	64x55x106	124	1
	SVC-N-3/30KVA	43.5x51.5x97	64x55x106	131	1
	SVC-N-3/45KVA	68x43x102	78x55x110	197	1
	SVC-N-3/60KVA	68x43x102	90x67x115	260	1
