● Single circuit output, high stability, high efficiency
● High current output
● Double-display for voltage and current
● Auto transfer between voltage stabilization and current stabilization
● Short circuit protection, current-limiting protection, the current-limiting
point can be adjusted randomly
● Plastic-sprayed steel frame, novel and nice appearance
● According to users' requirements, the output of fixed voltage and low
current of one circuit can be customized.
Main technical indexes
Model
Output
voltage
Output
current
HB17300SC7A
0~30V
0～7A
HB17300SC10A
0～10A
HB17300SC15A
0～15A
Ripple and noise: CV≤3mVrms
CC≤10mArms
Power supply effect : CV≤2×10-4＋3mV
CC≤2×10-3＋3mA
Load effect : CV≤2×10-4＋10mV
CC≤5×10-3+10mA
Volume and weight : 38×22×17 cm
11.5kg-15kg
